Heavy Duty Industrial Truck Scales 80T For Semi Truck Electronic Digital Type

Brand Name : OEM

Model Number : SCS-80T

Certification : ISO9001:2018

Place of Origin : Guangdong, China

MOQ : 1 set

Price : Negotiated price

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 Set/Sets per Month

Delivery Time : 10~25 days

Packaging Details : The platform of truck scale is nude packed and other electronic components is packed with carton box or wooden cases

Product Name : Semi Truck Scales

Capacity : 80 Ton

Accuracy : 20KG

Platform size : Custom

Power Supply : 220V/50HZ

Material : 10mm Thickness Q235 steel plate

Structure : U-shaped beams with 6pcs

Display : LED

Contact Now

Heavy Duty 80T Electronic Digital Semi Truck Scales for Sale

KEDA SCS Truck Scale Introduction:

With the high precision, good stability load cell and weighing indicator, SCS series electronic truck scales are pitless and high-performance weighing apparatus of main goods which are widely used in port, warehouse, factory, and freight yard. Optional accessories include Large display and PC weighing management system.

Features:

```
 Low profile deck design-30cm high
```
```
 Dimensions from 6x3m up to 24x3m
```

 Modular panels made of U or I steel beams with thickness 6/8mm

 Rolling surface composed of steel plate with high thickness 8/10/12/14mm

 Skidproof design for surface platform (optional)

 Easy access to load cells and junction box through removable access hatches on the surface platform

 High precision compression load cells, bridge type IP68 digital ZEMIC model with CE & OMIL certificate

 Finishing in industrial epoxy paint colour

```
 Suitable for an intensive usage.
```

Truck Scale Technical Paramater
Type	Digital truck scale
Platfrom size	From 6m to 24m
Platform material	8/10/12/14/16/20mm thickness top steel plate
Painting	poxy zinc rich primer and acrylic marine paint
Max. Cap	From 30ton to 150ton available
Accuracy	OIML Ⅲ
Safe over loade	150%F.S
Power supply	110V+-10%; 220V +-10% AC or DC, 50 or 60Hz
Load cell	Keli digital load cell or ZEMIC digital load cell
Weighing indicator	YAOHUA or Keda indicator
Interface	RS232 (or RS485), PC, printer, extra scoreboard
Working temperture	-10~40ºC(indicator), -30~75ºC(load cell)
Working humidity	≤95%
Certificate	CE, OIML, ISO9001:2015

Heavy Duty Industrial Truck Scales 80T For Semi Truck Electronic Digital Type

Recommended dimension for KEDA truck scale platform
Capacity(Tons)	30	40	50	60	80	100	120	150
Division Value	5KG/10KG/20KG/50KG
Platform size:L*W(m)	Recommended size								Packing(container)
3*7	√	√							1x20'GP
3*9	√	√	√	√	√				1x20'GP
3*12	√	√	√	√	√	√			1x20'GP
3*14	√	√	√	√	√	√			1x20'GP
3*16		√	√	√	√	√			1x20'GP
3*18			√	√	√	√	√		1x20'GP
3*20					√	√	√	√	1x40'GP
3*22						√	√	√	1x40'GP
3*24							√	√	1x40'GP
Remark	Other capacity, size and apprearance can be customized according your requirements.
